Specifications:

Product Description:

Designed for high-density fiber optic networks, our Single Mode Quad SC Footprint Fiber Optic Adapter delivers reliable, low-loss connectivity in a compact form factor. Featuring a flange mount design, this adapter ensures secure and stable panel installation, making it an ideal choice for telecommunication cabinets, data centers, and enterprise network infrastructures.

Key Features

Quad SC Configuration: Four SC ports in a single compact housing enable space-saving, high-density patching, optimizing rack and panel utilization.

Flange Mount Design: The integrated mounting flange allows for straightforward and robust panel attachment, simplifying installation and enhancing mechanical stability.

Single Mode Performance: Engineered for 9/125 µm single mode fiber, the adapter maintains precise physical contact (PC) or angled physical contact (APC) alignment, ensuring low insertion loss and high return loss for superior signal integrity.

RoHS Compliant: Manufactured in full compliance with RoHS (Restriction of Hazardous Substances) directives, this product meets global environmental standards, supporting your green procurement and sustainability goals.

Durable Construction: Precision-molded from high-performance engineering plastics with zirconia ceramic alignment sleeves, the adapter guarantees long-term durability and consistent optical performance across a wide operating temperature range.

Applications

Fiber optic patch panels and distribution frames

Optical network terminal (ONT) equipment

Local area networks (LANs) and wide area networks (WANs)

Telecommunication central offices and data centers

FTTx deployments and industrial control systems

Specifications (Typical)

Parameter

Specification

Fiber Type    Single Mode (9/125 µm)

Configuration    4 ports (Quad SC)

Mounting Type    Flange mount

Insertion Loss    ≤ 0.2 dB (typical)

Return Loss    ≥ 50 dB (PC) / ≥ 60 dB (APC)

Durability (Mating Cycles)    ≥ 500 times

Operating Temperature    -40°C to +75°C

Compliance    RoHS

Reliability You Can Count On

With rigorous quality control and adherence to international standards, this adapter is built to withstand the demands of mission-critical optical networks. Its flange mount design, combined with quad-port density, offers both flexibility and reliability for current and future fiber infrastructure needs.

For detailed technical drawings, custom flange configurations, or bulk order inquiries, please contact our sales team.
